Suprema
BioStation 3

Multiple Contactless Access Methods

  • Face Authentication

  • Mobile Access

  • QR and Barcode

  • RFID Card

What is
‘Face Template on Mobile’?
– Own Your Own Data

Suprema’s exclusive authentication method ‘Face Template on Mobile’ lets users enroll into an access control system and store their face profile directly on their own mobile devices. This gives the users complete control over their own ID and their privacy. Users’ biometric data is not stored in company databases.

Specification

Category Details BS3-DB BS3-APWB
CredentialRF Option125kHz EM, 13.56MHz MIFARE, MIFARE Plus, DESFire EV1/EV2*, FeliCa125kHz EM, HID Prox & 13.56MHz MIFARE, MIFARE Plus, DESFire EV1/EV2*, FeliCa, iCLASS SE/SR/Seos
RF Read RangeEM/HID iCLASS/MIFARE: 30 mm, HID Prox/SE/FeliCa: 25 mm, FeliCa: 15 mm
MobileNFC, BLE
Barcode and QR codeSupported
Crypto ChipSupported
GeneralCPU1.5GHz Quad Core
Memory32GB Flash + 4GB RAM
LCD Type5.5” IPS color LCD
LCD Resolution720 x 1280 pixels
Sound16bit
Operating Temperature-20°C ~ 50°C (-4°F ~ 122°F)
Operating Humidity0%~ 80%, non-condensing
Camera2MP x 2EA (Visual, IR)
Dimension (W x H x D)82.5mm x 177mm x 23.4mm
FaceWeightDevice: 370gDevice: 380g
Ingress Protection (IP)IP65
Vandal Proof (IK)IK06
CertificatesKC, CE, UKCA, FCC, RCM (Compliance: RoHS, REACH, WEEE)
FaceRecognition Distance0.6 ~ 1.0 m (23.6” ~ 39”)
Recognition Height1.4 ~ 1.9 m (5.1” ~ 7.4”)
Matching SpeedLess than 0.3 sec
Live Face Detection (Anti-Spoofing)Supported
CapacityMax. User100,000
Max. Credential (1:N)Face: 50,000
Max. Credential (1:1)Face: 100,000 / Card: 100,000 / PIN: 100,000
Max. Text Log5,000,000
Max. Image Log50,000
InterfaceEthernetSupported (10/100/1000 Mbps, automatic MDI/MDI-X)
Wi-FiSupported (802.11 b/g/n 2.4GHz)
RS-4851ch Host or Slave (Selectable)
Wiegand1ch Input and 1ch Output
TTL Input3ch Inputs
Relay1 Relay
PoE+–Supported (IEEE 802.3 at compliant)
IntercomSupported
USBUSB 2.0 (Host)
Extended USBSupported
TamperSupported
PowerDC 12 V 2.5A, DC 24 V 1.2A
